BGA Intel JHL8540 Thunderbolt 4 Retimer Chip

BGA Intel JHL8540 Thunderbolt 4 Retimer Chip

Intel
9E_intel_jhl8540
New

Intel JHL8540 is a Thunderbolt 4 Controller chip in a BGA package, used on laptop motherboards equipped with Thunderbolt 4 ports. The component is responsible for handling and controlling the Thunderbolt 4 port and is intended for professional electronics repairs.

  • Marking: Intel JHL8540
  • Chip manufacturer: Intel
  • Type: Thunderbolt 4 Controller
  • Package: BGA
  • Application: Thunderbolt 4 port in a laptop
Hurry! only 10 items left in stock.
zł48.00
Delivery in Poland 1-2 business days, in Europe 2-4 days.
Quantity

Add to Compare
Add to Wishlist

BGA Intel JHL8540 Thunderbolt 4 Chip for Laptops

Intel JHL8540 is an integrated circuit from the Thunderbolt 4 family (Thunderbolt 4 controller), used on laptop motherboards equipped with Thunderbolt 4 ports. The component is made in a BGA package and is intended primarily for professional electronics repairs.

The chip can be used as a spare part in case of damage to the original controller responsible for handling the Thunderbolt 4 port. BGA mounting requires specialized soldering equipment (rework station) and experience in electronics repairs.

Key features of the JHL8540 chip

  • Manufacturer: Intel
  • Marking: JHL8540
  • Chip type: Thunderbolt 4 Controller
  • Package: BGA
  • Application: Thunderbolt 4 port in laptops

What is the Thunderbolt 4 controller used for?

The Thunderbolt 4 controller manages communication and data transfer through the Thunderbolt 4 port, handling data transfer, video, and power in a single connector. Damage to this chip may manifest as the port not working, connected devices not being detected, or no image output via Thunderbolt.

Before purchase, check the chip marking

Before ordering, compare the full marking of the chip on the motherboard being repaired. The Intel JHL family includes both controllers and Thunderbolt/USB4 retimers with different functions.

We recommend selecting the chip based on the marking of the original component and the motherboard number, not solely on the laptop model.

Application

The Intel JHL8540 chip is intended mainly for:

  • laptop and electronics service centers,
  • technicians dealing with Thunderbolt port repairs,
  • professional BGA/SMD soldering stations.

Important: replacing a BGA chip requires professional point-mounting equipment (rework station). Before mounting, make sure that the chip marking matches the component on the motherboard being repaired.
